HS110 - Brass End Feed Fittings

HONSON HS110 end feed fittings satisfy your needs in installation of copper tube with capillary soldering. They are perfect for multiple applications including gas, heating and chilled water systems. They are specifically designed for connecting copper tubes in accordance with EN 1057. The end of the fitting for soldering is for metric tubing (in millimetres) under european standard. The end of thread is according to ISO 228. Mention again the convenience to use a sealant on the thread connection, such as hemp fibre or another such as Teflon or similar.

Structure

Product Technical Document
Features

  • Ideal for use in multiple applications

  • Wide range of fittings in sizes 10-108mm

  • WRAS Approved.

  • Marked for full traceability

  • Made from high quality brass material

  • Compliant with relevant British standards EN1254-1 / BS864

Straight Coupler
Female Straight Coupler C×FI, HS110-001
Inquiry
SIZEDGLL1L2
10×1/4"F101/4"18.57.89
10×3/8"F103/8"18.57.89
10×1/2"F101/2"20.57.811.5
12×3/8"F123/8"198.69
12×1/2"F121/2"218.611.5
14×3/8"F143/8"2110.69
14×1/2"F141/2"2310.611.5
14×3/4"F143/4"24.510.613
15×1/4"F151/4"19.510.69
15×3/8"F153/8"2110.69
15×1/2"F151/2"2310.611.5
15×3/4"F153/4"24.510.613
16×3/8"F163/8"2110.69
16×1/2"F161/2"2310.611.5
16×3/4"F163/4"2410.613
18×1/2"F181/2"2512.611.5
18×3/4"F183/4"2712.613
22×1/2"F221/2"2815.411
22×3/4"F223/4"29.515.413
22×1"F221"31.515.414
28×1/2"F281/2"32.518.411.5
28×3/4"F283/4"3218.412
28×1"F281"34.518.414
28×11/4"F2811/4"3718.416
32×11/4"F3211/4"40.52316
35×1"F351"392314
35×1.1/4"F351 1/4"40.52316
40×1 1/2"F401 1/2"44.52716
42×1 1/2"F421 1/2"44.52716
54×2"F542"533219.5
67×2 1/2"F672 1/2"56.532.522
76×3"F763"6033.524
108×4"F1084"774826
Male Straight Coupler C×MI, HS110-002
Inquiry
SIZEDGLL1L2
10×1/4"M101/4"187.88.5
10×3/8"M103/8"18.57.89
12×3/8"M123/8"198.69
12×1/2"M121/2"19.58.69.5
14×3/8"M143/8"2110.69
14×1/2"M141/2"19.510.69.5
14×3/4"M143/4"21.510.611
15×1/4"M151/4"2110.68.5
15×3/8"M153/8"2110.69
15×1/2"M151/2"19.510.69.5
15×3/4"M153/4"21.510.611
16×3/8"M163/8"2210.69
16×1/2"M161/2"19.510.69.5
16×3/4"M163/4"21.510.611
18×1/2"M181/2"23.512.69.5
18×3/4"M183/4"2512.611
22×1/2"M221/2"26.515.49.5
22×3/4"M223/4"27.515.411
22×1"M221"2715.412.5
28×3/4"M283/4"31.518.411
28×1"M281"31.518.412.5
28×11/4"M2811/4"3418.414.5
32×1"M321"392312.5
32×1 1/4"M321 1/4"332314.5
35×1"M351"37.52312.5
35×1 1/4"M351 1/4"332314.5
35×1 1/2"M3511/2"42.52316
40×1 1/2"M401 1/2"432716
42×1 1/4"M421 1/4"44.52714.5
42×1 1/2"M421 1/2"442716
52×2"M522"49.53217
54×2"M542"503217
64×2 1/2"M642 1/2"5332.519
67×2 1/2"M672 1/2"5332.919
76×3"M763"4833.521
108×4"M1084"764823
View All
Stop Cap, HS110-011
Inquiry
SIZEDLL1
121210.38.6
141412.310.6
151512.310.6
181814.512.6
Tee Trap, HS110-019
Inquiry
SIZEDLL1
12×121217.811
14×141417.811
16×16162213
18×18182213
View All
Female Straight Coupler C×FI, HS110-021
Inquiry
SIZEDGLL1L2
12×3/8123/8"198.58.5
12×1/2121/2"2089.5
14×3/8143/8"19.5108
14×1/2141/2"20109
14×3/4143/4"23910
16×3/8163/8"19.58.59
16×1/2161/2"20.589
16×3/4163/4"2311.510
18×1/2181/2"22119.5
18×3/4183/4"2311.510
22×3/4223/4"2513.510.5
22×1221"2813.512
28×1281"281512.5
32×1321"2813.512
32×11/4321 1/4"371914
40×11/2401 1/2"371915
42×11/2421 1/2"371915
View All
Elbow
Female Elbow C×FI, HS110-003
Inquiry
SIZEDGLL1HH1
12×3/8"F123/8"16.58.6168.5
12×1/2"F121/2"178.619.511.5
14×3/8"F143/8"17.510.6178.5
14×1/2"F141/2"17.510.620.511.5
15×3/8"F153/8"1810.617.58.5
15×1/2"F151/2"1910.621.511.5
15×3/4"F153/4"2010.622.513
16×1/2"F161/2"1810.62111.5
16×3/4"F163/4"2010.62313
18×1/2"F181/2"2212.62311.5
18×3/4"F183/4"2312.624.513
22×1/2"F221/2"26.515.42411.5
22×3/4"F223/4"26.515.42613
22×1"F221"2815.42814
28×3/4"F283/4"3218.42913
28×1"F281"3218.43014
28×1 1/4"F281 1/4"3318.43316
35×1 1/4"F351 1/4"372339.517.5
42×1 1/2"F421 1/2"452741.518
54×2"F542"57.53251.522
View All
Male Elbow C×MI, HS110-004
Inquiry
SIZEDGLL1HH1
12×3/8"M123/8"158.6209
12×1/2"M121/2"178.6229.5
14×3/8"M143/8"17.510.6219
14×1/2"M141/2"1910.623.59.5
15×3/8"M153/8"17.510.6219
15×1/2"M151/2"1910.623.59.5
15×3/4"M153/4"2110.62411
16×1/2"M161/2"1910.623.59.5
16×3/4"M163/4"2110.624.511
18×1/2"M181/2"21.512.6259.5
18×3/4"M183/4"2712.62711
22×1/2"M221/2"2515.4279.5
22×3/4"M223/4"2715.43011
22×1"M221"2715.43212.5
28×3/4"M283/4"3018.432.511
28×1"M28130.518.433.512.5
35×1 1/4"M351 1/4"40233714.5
42×1 1/2"M421 1/2"462747.516
54×2"M542"57.5325017
View All
Wall Plate Elbow C×FI, HS110-005
Inquiry
SIZEDGLL1HH1H2
12×1/2"F121/2"178.627.519.511.5
14×1/2"F141/2"1910.630.52111.5
15×1/2"F151/2"1910.630.52111.5
15×3/4"F153/4"2010.632.522.513
18×1/2"F181/2"2212.634.522.511.5
18×3/4"F183/4"2312.63624.513
22×1/2"F221/2"26.515.43723.511.5
22×3/4"F223/4"26.515.4402613
Tee Trap Square, HS110-020
Inquiry
SIZEDLL1H
12×121217.81119
14×141417.81119
16×1616221324
18×1818221324
Tee & Cross
Female Tee C×C×FI, HS110-006
Inquiry
SIZEDGLL1HH1
12×12×1/2"F121/2"348.619.511.5
14×14×1/2"F141/2"3510.62111.5
15×15×3/8"F153/8"3310.6189
15×15×1/2"F151/2"3510.62111.5
16×16×1/2"F161/2"3610.621.511.5
18×18×1/2"F181/2"4412.622.511.5
18×18×3/4"F183/4"4612.624.513
22×22×1/2"F221/2"5315.423.511.5
22×22×3/4"F223/4"5315.42613
28×28×1/2"F281/2"5918.427.511.5
28×28×3/4"F283/4"6418.42913
28×28×1"F281"6418.43014
Equal Cross C×C×C×C, HS110-007
Inquiry
SIZEDLL1
15154210.6
18184712.6
22225715.5
28286918.4
35358623
Union
Straight Conical Union with Metal Sealing C×C, HS110-008
Inquiry
SIZEDLL1
15×151544.511.5
16×161644.511.5
18×181849.512.6
22×222264.515.5
28×28286618.4
35×35358123
Straight Conical Union with Metal Sealing C×MI, HS110-009
Inquiry
SIZEDGLL1L2
12×3/8"M123/8"40119
12×1/2"M121/2"44.51110.5
14×3/8"M143/8"40119
14×1/2"M141/2"44.51110.5
14×3/4"M143/4"511112
15×1/2"M151/2"45.511.510.5
15×3/4"M153/4"5211.512
16×1/2"M161/2"45.511.510.5
16×3/4"M163/4"5211.512
18×1/2"M181/2"47.512.610.5
18×3/4"M183/4“5312.612
22×3/4"M223/4”58.515.512
22×1"M221“65.515.514
28×3/4"M283/4"6718.513.5
28×1"M281”65.518.414
28×11/4"M2811/4“6718.516
32×1"M321”65.52314
35×11/4"M3511/4“782316
40×11/4"M4011/4“762716
40×11/2"M4011/2“842717
42×11/2"M4211/2“842717
52×2"M522“1003220
54×2"M542“1003220
View All
Angel Conical Union with Metal Sealing C×FI, HS110-010
Inquiry
SIZEDGLL1HH1
14×1/2"F141/2"42.51120.510.5
15×1/2"F151/2"4311.520.510.5
16×3/4"F163/4"47.511.525.512
18×3/4"F183/4"48.512.625.512
22×3/4"F223/4"48.515.525.512
22×1"F221"60.515.53113.5
28×1"F281"6218.43113.5
35×11/4"F3511/4"75233615.5
Straight Conical Union with Metal Sealing C×FI (Light Duty), HS110-016
Inquiry
SIZEDGLL1L2
12×3/8"123/8"29119
12×1/2"121/2"371110.5
14×3/8"143/8"29119
14×1/2"141/2"391110.5
14×3/4"143/4"40.51114
15×1/2"151/2"39.511.510.5
15×3/4"153/4"40.511.514
16×1/2"161/2"39.511.510.5
16×3/4"163/4"41.511.514
18×1/2"181/2"37.512.610.5
18×3/4"183/4"42.512.614
22×3/4"223/4"42.515.514
22×1"221"49.515.514
28×1"281"5118.514
28×1 1/4"281 1/4"54.518.515.5
32×1"321"522314
32×1 1/4"321 1/4"62.52315.5
35×1 1/4"351 1/4"62.52315.5
40×1 1/2"401 1/2"57.52717
42×1 1/2"421 1/2"57.52717
54×2"542"773220
View All
Angle Union with Metal Sealing C×MI, HS110-017
Inquiry
SIZEDGLL1HH1
14×1/2"141/2"44.510.520.510.6
16×1/2"161/2"44.510.520.511.5
16×3/4"163/4"51122411.5
18×3/4"183/4"51122613
22×3/4"223/4"51122915.5
28×1"281"61.5143418.5
2 Pieces Female Adaptor, HS110-018
Inquiry
SIZEDGLL1
10×3/8"103/8"1110.5
12×3/8"123/8"1110.5
10×1/2"101/2"12.510.5
12×1/2"121/2"12.510.5
14×1/2"141/2"12.511.5
14×3/4"143/4"1311.5
16×3/4"163/4"1311.5
18×3/4"183/4"1312.5
22×1"221"1516
Straight Conical Union with Metal Sealing CxMI (Light duty), HS110-022
Inquiry
SIZEDGLL1L2
10×3/8103/8"32.5108
12×3/8123/8"34.598
12×1/2121/2"3598.5
14×3/8143/8"35.5·98
14×1/2141/2"3698.5
14×3/4143/4"38910
16×1/2161/2"41119
16×3/4163/4"42.511.510.5
18×1/2181/2"4111.59.5
18×3/4183/4"4211.510.5
22×3/4223/4"43.5139.5
22×1221"471311.5
28×1281"55.51912
28×11/4281 1/4"581713
32×1321"571712
32×11/4321 1/4"581713
32×11/2321 1/2"59.51714
35×11/4351 1/4"652213
40×11/4401 1/4"672215
40×11/2401 1/2"672215
42×11/4421 1/4"682215
42×11/2421 1/2"682215
52×2522"81.53016
54×2542"81.53016
View All
Straight Conical Union with Metal Sealing C×FI (Light Duty), HS110-023
Inquiry
SIZEDGLL1L2
12×3/8123/8"3398
14×3/8143/8"33.598
14×1/2141/2"35.599
14×3/4143/4"37.5910
16×1/2161/2"38119
16×3/4163/4"40.511.59.7
18×1/2181/2"3611.59.5
18×3/4183/4"40.511.59.7
22×3/4223/4"421310
22×1221"43.51311.5
28×3/4283/4"53.51912.5
28×1281"54.51912.5
28×11/4281 1/4"561714
32×1321"53.51711
32×11/4321 1/4"55.51714
32×11/2321 1/2"571714
35×11/4351 1/4"652213
40×11/2401 1/2"642218
42×11/2421 1/2"652218
52×2522"74.52218
View All
Tap Connector
Angel Conical Union with Metal Sealing C×MI, HS110-012
Inquiry
SIZEDGL
10×3/8"F103/8"7.8
12×3/8"F123/8"8.6
12×1/2"F121/2"8.6
14×3/8"F143/8"10.6
14×1/2"F141/2"10.6
14×3/4"F143/4"10.6
15×1/2"F151/2"10.6
15×3/4"F153/4"10.6
16×1/2"F161/2"10.6
16×3/4"F163/4"10.6
18×1/2"F181/2"12.6
18×3/4"F183/4"12.6
18×1"F181"12.6
22×1/2"F221/2"15.4
22×3/4"F223/4"15.4
22×1"F221"15.4
28×1" F281"18.4
32×1 1/4" F321 1/4"23
40×1 1/4" F401 1/2"27
View All
Straight Tap Connector with Hole C×FI, HS110-013
Inquiry
SIZEDGL
12×1/2"F121/2"8.6
14×1/2"F141/2"10.6
15×1/2"F151/2"10.6
15×3/4"F153/4"10.6
18×1/2"F181/2"12.6
18×3/4"F183/4"12.6
18×1"F181"12.6
22×1/2"F221/2"15.4
22×3/4"F223/4"15.4
22×1"F221"15.4
28×1"F281"18.4
Bent Tap Connector C×FI, HS110-014
Inquiry
SIZEDGL
12×3/8"F123/8"8.6
12×1/2"F121/2"8.6
14×3/8"F143/8"10.6
14×1/2"F141/2"10.6
14×3/4"F143/4"10.6
15× 1/2"F151/2"10.6
15×3/4"F153/4"10.6
16×1/2"F161/2"10.6
16×3/4"F163/4"10.6
18×1/2"F181/2"12.6
18×3/4"F183/4"12.6
18×1"F181"12.6
22×1/2"F221/2"15.4
22×3/4"F223/4"15.4
22×1"F221"15.4
28×1"F281"18.4
View All
Bent Tap Connector C×FI, HS110-015
Inquiry
SIZEDGL
12×1/2"F121/2"8.6
14×1/2"F141/2"10.6
15×1/2"F151/2"10.6
15×3/4"F153/4"10.6
18×1/2"F181/2"12.6
18×3/4"F183/4"12.6
18×1"F181"12.6
22×1/2"F221/2"15.4
22×3/4"F223/4"15.4
22×1"F221"15.4
